Harley-Davidson FLD Switchback 2012
|
Engine and transmission
|
|
| Engine type: | 2 cylinders, 4-stroke, V-twin |
| Displacement: | 1690 cc (103.26 cubic inches) |
| Bore × stroke: | 3.87 inch × 4.37 inch (undersquare - longstroke) |
| Cooling system: | Air cooled |
| Torque: | 136 Nm (100.31 lb-ft) @ 3500 rpm |
| Throttle: | Cable operated |
| Valves | |
| Valve train: | OHV, non-variable |
| Valves per cylinder: | 2 |
| Fuel and ignition | |
| Sparks per cylinder: | 1 |
| Fuel supply system: | Fuel injection |
| Compression: | 9.6:1 |
| Engine mounting: | Transverse |
| Lubrication system: | Dry sump |
| Gear box: | Manual 6-speed |
| Clutch: | Wet, multiple discs, cable operated |
| Final drive: | Belt |
| Starter: | Electric |
|
Dimensions
|
|
| Physical measures | |
| Length: | 92.8 inch |
| Width: | 37.7 inch |
| Height: | 55.5 inch |
| Wheel base: | 62.8 inch |
| Trail: | 5.8 inch |
| Ground clearance: | 4.33 inch |
| Seat height: | 26.1 inch |
| Weight | |
| Curb weight: | 718.7 lbs |
| Dry weight: | 696.7 lbs |
|
Chassis and suspension
|
|
| Frame type: | steel, Backbone frame |
| Front | |
| Suspension: | Cartridge |
| Suspension travel: | 3.86 inch |
| Fork angle: | 29° |
| Brake: | Twin Disk, Ø11.81 inch |
| Tire: | 130 / 70 R18 |
| Rear | |
| Suspension: | twin shock, Swingarm |
| Suspension travel: | 2.13 inch |
| Brake: | Disk, Ø11.5 inch |
| Tire: | 160 / 70 R17 |
|
Other
|
|
| ABS available: | No |
| Fuel capacity: | 4.7 gals |
| Number of riders: | 2 persons |
